How to work around the mouse math bug in DaVinci Resolve

September 21, 2016

In an earlier video we showed you the 'mouse math bug' when color correcting in DaVinci Resolve—now learn how to work around it.


Series

Part 2: Exploring Three Workarounds (and finding another Mouse UI Problem)

In theory, the only difference between color correcting in DaVinci Resolve on a control surface vs. using a mouse is your movements. With a mouse, you make only one adjustment at a time. With a control surface, you make multiple adjustments simultaneously. But the actual math behind using the two different input devices should be the same, in theory. As we all recently discovered, the theory doesn’t match reality. Watch my previous Insight on the ‘Mouse Math Bug’ if you haven’t already. It’ll give you the full details of the surprising difference between grading with a mouse vs. with a control surface.

Is this ‘Mouse Math Bug’ really a difference in math and is it truly a bug?

I’ve come to the conclusion that no, it’s not a difference in math. Based on my experimentation and some new information gleaned from a short email response to me from Blackmagic… this behavior is not intentional. In fact, it looks like Blackmagic found another bug’ish behavior when using a mouse in the Primary Bars interface. Since this behavior is not intentional and since it actually makes color grading with a mouse harder than color grading with a control surface and since this new Primary Bars behavior is definitely not helpful… I’m comfortable calling this a bug. Even if some of my more accomplished peers disagree with this assessment (which is fine, diversity of opinion is what makes our lives worth living).

In this Insight, you’ll see a new bug in action

It has to do with a mouse shortcut that allows us to make YRGB moves when using the Primary Bar interface (which typically only allows for a single color channel adjustment at a time). This new bug was suggested to me in a very short email from Blackmagic. They asked me to confirm what they were seeing on their end. This is good news since it means the Resolve team is digging into this.

While coming up with workflow suggestions for dealing with these bugs, I discovered another little quirk in the Primary Bars that is 100% repeatable. But it is only evident is very specific situations using a mouse.

You’ll also learn three solid strategies for dealing with this Mouse Math Bug.

In the video below I share three techniques for mouse-based colorists to work-around this bug:

  • In the comments for Part 1 of these Insights, lots of members shared their long-time workflow for dealing with this problem. Break up your initial color balancing adjustments into two nodes. It’s a good way of solving this problem but at the cost of extra nodes and complexity to your Node Graphs.
  • Another common suggestion was to follow up on your color balancing adjustments in the color wheels with a Y-only move in the Primary Bars. You’ll see that solution in action, plus my thoughts on why it’s not always appropriate.
  • Finally, I found a 100% solid workaround. It involves using Curves to solve color balance issues. Follow up the curves adjustment with a Master Wheel adjustment in the same node—and you get the same behavior as on a control surface.

As always, leave your comments, thoughts, and suggestions below!

Enjoy!

-pi


Comments

Homepage Forums How to work around the mouse math bug in DaVinci Resolve


  • Marc Wielage
    Member

    Great work, Patrick. This is a puzzling mystery.

    I would also point to Offsets and also Lum Mix = 0 as being additional alternatives to solve initial balance problems. I never use the GUI, but these modes can be useful under some circumstances.


  • R.NeilHaugen
    Guest

    Liked the curves/luma combo. And btw … the new light is much softer on you .. 😉

  • This is awesome, thanks Patrick! There’s one other mouse bug which drives me crazy (at least I think it’s a bug!). When changing the ISO in the raw controls you can drag down and it works fine but if you drag up you have to drag the mouse quite far for it to move up to the next value and then beyond that it ramps up like crazy. It’s so fiddly it’s ridiculous.


  • Patrick Inhofer
    Guest

    RE: Soft light – 🙂 Yeah, I pulled out an old Soft Box to see what I think. The color temp of the bulb is all off but I like the overall result much better.


  • Patrick Inhofer
    Guest

    Well – this particular bug is limited to the Gain / Lift controls – which Offset doesn’t replicate. I also tried working the 3-Ways with Lum Mix = 0… it doesn’t change this behavior for mouse-based colorists 🙂 Currently, the best work-around to get that ‘control surface math’ is to do the color balance using Curves with the Lift / Gain Master Wheels for setting white and black points.


  • Patrick Inhofer
    Guest

    Be sure to go back to Part 1 of this series where I provide links to complain about the ISO behavior with a mouse. The only way to be sure that your complaint makes it onto their radar is to tell them directly.
