4 Things To Know About Working With LUTs

March 4, 2016

Using Luts in a color correction workflow is common, but everything doesn't always worked as planned. Learn 4 ways to work around look up table limitations


Clearing Up Common Confusions About Working With Look Up Tables

I remember the moment clearly.

It was 2007 at the Post | Production World conference at NAB and I was giving a talk on color correction and I asked how many of those in attendance had heard of or had used a LUT before.

One maybe two hands went up.

Over the years, steadily & predictably, as Log and Raw acquisition tools have become more accessible to more people, attendees at similar sessions when I’ve asked if they heard of or used LUTS have increasingly raised their hands.  Indeed, at one session this past year I think everyone in the room raised their hand.

Clearly, LUTs have a place in many on-set, editorial and finishing workflows.  However, a few things have stuck out to me over the past few years as more and more people have started using LUTs.  At conferences, Dan, Patrick and myself all get asked about LUTs, and recently with our team.ml@mixinglight.com account we’ve received dozens of questions about using LUTs.

Here is a small sampling of those questions:

‘I’m looking for a LUT to make my (insert camera here) look great.  I’ve tried several LUTs from the web, but none of them look good – help!’



‘I’ve watched several tutorials on using LUTs, but no matter what LUTs I use none of them look good with my footage…what am I missing?’



‘I’m so confused about LUTs!  Seems like there are many different kinds…Input LUTs, Creative LUTs, Display LUTs, Calibration LUTs. Which should I use?’

Over many different Insights and in many different ways Dan, Patrick and I have explained LUTs, how we use them, and best practices including some that I’ll go over again in this Insight,  but that info is spread out across dozens of videos and articles here on mixinglight.com and some of those articles are from a years ago (yes, we are entering our fourth year of operation)!

This Insight is about avoiding the common mistakes/pitfalls you’re likely to make with Look Up Tables (LUTs)

After defining the different types of LUTs, I’ll share with you my top 4 insights to working successfully with them.

Camera Patch? Input LUT? Creative LUT? Display LUT? What the LUT?!

Before I dive into the four specific things about working with LUTs, lets spend a moment to discuss what is a big point of confusion:

What are LUTs are used for, and why do people call them all sorts of different things?

The most simplified way of thinking of LUT is that its just dumb math.

Meaning, a LUT takes an incoming RGB pixel, applies the math of the LUT, and produces an output RGB pixel.

If you wanted to think about this as math, then think R= S + L.  Where R is the result, S is the signal and L is the lookup table.

A LUT converts, changes, transforms (or what other verbs you want to use) one set of RGB pixel data (the incoming signal) into another set of RGB pixel data (the outgoing signal).

The math of getting this done is provided by a 1D or 3D lookup table. Mixing Light friend Steve Shaw from Light Illusion has a great article on 1D Vs 3D LUTs so check that out (thanks Steve for saving me a thousand words!) And Patrick also has an Insight on 1D vs 3D LUTs, talking about it in a less technical manner.

While 1D LUTs are sometimes used in color correction workflows, most commonly, when color correcting, you’ll be working with 3D LUTs. Here is how I tend to think of the different uses of LUTs:

  • Calibration LUTs – A Calibration LUT is used to make sure that a reference monitor adheres to a standard – like REC 709, P3, etc.  Calibration LUTs are created with software like Calman or Lightspace. LUTs created by calibration tools are then uploaded to the display and activated. A Calibration LUT can also be used as a display LUT if a monitor doesn’t specifically allow Calibration LUT uploads or if a LUT box is not available.
  • A Display LUT – Cameras and on-set monitors often employ Display LUTs. How is this different from a Calibration LUT? Let’s say you recorded in Arri Log-C on an Alexa. Of course, that’s going to be pretty flat and desaturated. By activating a Log- C Display LUT on your on-set monitor you can display that LOG C shot as REC 709 (using an Arri Log-C to Rec. 709 Display LUT). This doesn’t change the actual recording, but rather is used simply for monitoring. In more sophisticated setups with a DIT involved and using software like Pomfort’s Live Grade, one can, in real-time, create a display LUT to show off ideas for the actual grade – again this process doesn’t alter the original footage.
  • Display LUT Type 2 – A hybrid of the calibration/display LUT is what many people also call a display LUT—or sometimes an emulation LUT. For example, you’re having a 35mm print made of a film you graded. The lab can provide you with a LUT to mimic the look and feel of the 35mm film stock that’s been chosen.  In software, you’d apply this LUT to your entire timeline as a display LUT, grade the film with the display LUT in place, and then prior to rendering take the display LUT off.  I’ve also used display LUTs like this in situations where the performance of a display was non-standard – a JumboTron at a football stadium for example.  The JumboTron team provided me with a 3D display LUT to use while grading. Some tools using a category of LUTs called output LUTs will simply bake this type of LUT into the final render, but control of that is usually separate from a true display LUT.
  • Camera Patch (or Input) LUTs – The postproduction cousin to the Display LUT is the Camera Patch LUT or the Input LUT (two names for the same thing). These LUTs are often used as a starting point for the rest of your grading and based (hopefully) on the specific colorimetry of the camera used on set. You might use a Sony S-Log 2 > Rec 709 Input LUT to transform the flat Log-recorded image from the Sony camera to a normal(ish) looking shot. No matter how marketing tries to sell it, these types of LUTs are NOT magic bullets. They are designed to snap contrast and make the image look ‘normal’. Because of the dumb math involved you’ll often have to massage a shot for the Input LUT to properly do its job. These LUTs can be (usually, depending on your software) applied either before color correction operations, after color correction operations or somewhere in the middle of your color correction operations.
  • Creative LUTs – Applied in a similar fashion to an Input LUT, Creative LUTs take things a step further by applying clear ‘looks’ to shots vs. just making it look ‘normal’ as with an Input LUT. You might apply a Creative LUT that attempts to mimic the look of a film stock, or a popular look (bleach bypass for example). Like Input LUTs, a Creative LUT is not one size fits all; tweaking before and after the LUT is often needed. In fact, some Creative LUTs specifically require that the image is normalized (often with a Camera Patch) before applying the Creative LUT.
  • Technical LUTs – Finally, the last broad category of LUTs are technical ones. These types of LUTs can do things like general color space and gamma transforms or provides other overall signal changes. For example, last week I pulled a project from LTO that I worked on 5 years ago and it was graded on a 2.2 gamma display, but now I’m working on 2.4. I applied on the timeline level in Resolve a 2.2 Gamma > Linear LUT and then a Linear > 2.4 Gamma LUT to make the conversion of the entire timeline.

That clears it up right?  LOL!

Not only does the use of LUTs differ, but LUTs also come in several formats

.cube, .3DL, .look are common formats. They also come at various sizes, with ‘bigger’ LUTs being more accurate. A 33x33x33 LUT provides more accuracy than an 8x8x8 LUT.

What makes things (more) confusing is the naming of LUTs

Many LUT sellers use names for LUTs that make them ambiguous as to how you should be using them. Sometimes, the same LUT can often be used for different purposes. If you’re trying to use LUTs, there’s a certain amount of confusion that you’ll simply have to get used to when figuring out what LUTs should be used when and where.

Also, keep in mind different software utilize LUTs in different ways. In Premiere Pro, there is an actual pull-down in the Lumetri Color Panel for choosing an input LUT, and a separate pull down for a Creative LUT—but, if you know what you are doing, there’s no reason you can’t choose to place a Creative LUT using the pull-down for the Input LUT.

Resolve allows you to apply LUTs in a multitude of different places and different ways depending on your needs – you can apply LUTs on the clip and timeline levels in the node graph, or use pulldown menus setting for input and display LUTs in the Color Management section of Project Settings.

With all this as a preamble—and yes, you do need to be aware of all the main categories of LUTs that I just described; you’ll most often be using and working with Input LUTs and Creative LUTs.

Defining a few rules for using LUTs in your color correction pipeline…

And then, in the end, I’ve recorded a Video Insight to put this into action and help you work more successfully with LUTs.

Member Content

Sorry... the rest of this content is for members only. You'll need to login or Join Now to continue (we hope you do!).

Need more information about our memberships? Click to learn more.

Membership options
Member Login

Are you using our app? For the best experience, please login using the app's launch screen


Comments

Homepage Forums 4 Things To Know About Working With LUTs


  • Marc Wielage
    Member

    Ah, I feel better now. In truth, I have used LUTs going back to 2002 — the only colorist I know who’s done it longer is Jill Bogdonovich — and technical LUTs have their use, particularly in going from digital back out to film. But I get weary of people saying, “just use this magic LUT and Camera X will look just like Kodak blah-blah negative stock.” Just ridiculous. I agree 100% with Robbie’s conclusions above.

  • It would be so cool if resolve could take a lut applied to a node and translate it to adjustments in the various panes.


  • pauljohndore
    Guest

    I know that this insight is listed as ‘beginner’ level of difficulty, but it is still frustrating to be presented with yet another discussion on LUTs that doesn’t really explain much. It’s like an attempt to explain them to people who are allergic to formulas and math. After spending the best part of a year trying to understand the core functionality and make-up of LUTs (with particular regards to Resolve) I decided to have a go and build them from the ground up, thereby gaining a truer understanding of the actual math.

    I posted my findings here:

    http://www.magiclantern.fm/forum/index.php?topic=15801.msg158237#msg158237

    If you’re going to discuss LUTs you should always prioritise mentioning the specific input and output colour space (gamma) and primaries (gamut). Anything that doesn’t do this (including Denver Riddles’s ‘Look’ LUTs) should not be considered professional. With enough experience a colourist can learn to tell what a LUT will do to footage just by looking at it in a text editor, and that would represent actual progress in demystifying what is an essential (whether you like it or not) component in the modern grading process.

  • Even if Resolve could, it would be using a variety of math algorithms that all have very different looking final results, but technically reverse the look into curves or other controls. That said, manually doing this is a fantastic exercise that I try and do with any LUT presented to me.

    Apps like 3D LUT Creator can do this to an extent, but you’ll discover its very much a artist based decision on which method to use and to what extent. Its not something I feel would translate well to an “auto” function ….yet.

  • While everything you say is valid, i feel you should remember that everyone has a different background before coming to color. While technically oriented colorists (especially with deep VFX backgrounds) can understand LUTs via opening the text file, its another language to those less familiar with it. Apps like Lattice and Lightspace CMS allow those less technically inclined to still do professional LUT manipulation using more visual methods without digging into the “numbers”.

    One of the best points Robbie made was you CAN grade without any LogC – Rec709 transform, and while the primaries may not be converted from Arri Wide Gamut to Rec709, we can easily make it work and it can still look good, sometimes faster than using any LUT.


  • Patrick Inhofer
    Guest

    “If you’re going to discuss LUTs you should always prioritise mentioning the specific input and output colour space (gamma) and primaries (gamut). Anything that doesn’t do this . . . should not be considered professional.”

    I couldn’t disagree more… including proclaiming what is professional and what isn’t.

    If a LUT designed for DCI P3 gives me the look I want in Rec. 709… then it’s perfectly acceptable to use. Creative LUTs / Look LUTs are just what the name says. They don’t need to be technically accurate—not any more than a preset in Magic Bullet Looks needs to be technically accurate (whatever that would mean).

    It’s only when dealing with Technical LUTs that they’re either (mostly) right or (mostly) wrong. And I say ‘mostly’ because in the Rec.709 > DCI P3 translation major post houses often have their own proprietary ‘blend’ when doing this technical translation. Are they un-professional if they vary from each other? Or is there much broader latitude in the science than meets the eye? I say, it’s the latter.

    That said, I agree—there is nothing ‘beginner’ about any discussion of LUTs. I’ve modified this post to ‘Intermediate’. I also recommend, as you walk down the road of understanding LUTs, that you check out the other Insights Robbie links to. Team Mixing Light has a fairly consistent approach to working with LUTs even though all three of us have different client bases.

    Also – I’ve bookmarked your post for closer reading. It looks interesting.


  • pauljohndore
    Guest

    Although I still would have issue with your specific example of using a LUT for a purpose other than its stipulated intention, with regards to the quoted statement I would say that although I press for what I feel is proper labelling I’m not saying you can’t use LUTs for unoriginally intended purposes, it’s just that those original purposes should always be know.

    There should be no scope for ‘mostly’ when you actually know the math involved. If there are two ‘different’ Rec.709 > DCI P3 LUTs, then that should be traceable back to the gamma transform involved, by way of an expression applied to a known set of linearly spaced input values. The primaries (gamut) transform is always based on a fixed 3×3 matrix. The word ‘blend’ shouldn’t come into it, unless you don’t understand the basic math and prefer to comprehend things in the form of ‘feels’. I had a quite sobering discussion with a very renowned VFX compositor recently where the general state of colourist capability was lamented, and regarded with a mixture of disdain and frustration. I’m afraid I had little reason to disagree with him.

    I’ve been a member of Mixing Light for around 6 months now, and have viewed pretty much every video (including the ones concerning LUTs). Thank you for the recommendations, and I hope you find something of informative value in the link I posted.


  • Patrick Inhofer
    Guest

    RE: “The primaries (gamut) transform is always based on a fixed 3×3 matrix. The word ‘blend’ shouldn’t come into it, unless you don’t understand the basic math and prefer to comprehend things in the form of ‘feels’.”

    The one thing we shouldn’t lose in this discussion that while it’s absolutely correct to say ‘the math is either right or it is wrong’, we shouldn’t leave out of this discussion… ‘does the image still look right?’

    The math may be precise but often the image loses some of its original feeling. It’s like the difference grading on a 15″ display and then viewing it on a 75″ display… the math is precisely the same but the feel is completely different and you’ll feel the urge to do a trim pass. That’s what happens in many Rec 709 > DCI P3 trims… a precise math transform is only the beginning.

    But the end is all about the human eye and how it interprets the image. If my eye tells me I need to adjust the image after applying a technical LUT that is 100% accurate… I’m adjusting the image.


  • Robbie Carman
    Guest

    Hi Paul –

    Sorry for chiming in late – I was on a flight to Dubai for a project, and the plane didn’t have working Wifi (the horror!)

    You bring up a lot of great points let me address some of them:

    1. Yes, my intention with this article/video was not to cater to the more advanced user how wants to dive to the particulars of the matrices, rounding errors or other math particulars, but my goal was to do two things – recap some previous thoughts on LUTs by Dan/Pat and to address general questions we’ve been getting recently about lookup tables in a conceptual/workflow sense. What I published was never meant to be a mathematical explanation of everything LUTs (obviously).

    So I do understand your comment about lack of specificity on the math in this and other articles/videos for this site and elsewhere, I really do. But I also think there are two levels of learning involved here: concept/general implementation & workflow and then as you’ve pointed out the mathematical details and processes/thinking that go in to building a capable LUT

    I can totally see a series on the math side of LUTs that might appeal a bit more to what you bring up here and maybe to other readers.

    Interested in contributing? (totally serious)

    2. I do agree that the lack of input/output information in naming related to gamut/gamma or even ETOF PQ info as is the case with HDR LUTs these days is frustrating. And I mentioned that in the article I see this as a big problem – but at the same time that technical information goes well over the head of the purchasing public that many LUT developers are trying to target – i.e. editors, enthusiasts etc. ‘Awesome Thriller Look’ is more marketable and more approachable for that audience.

    And that audience is clearly the target of many a LUT producer (because as I mentioned they’re looking for easy ‘fixes’ and ‘looks’) – not a colorist willing to breakdown the math of a particular LUT – in those cases, as you pointed out, that colorist probably makes their own LUTs for their particular needs anyway as you did! Or has a team of color scientists on staff to create their in house LUTs as groups like CO3 and other large outfits do.

    But I don’t think its fair to call a LUT or a LUT producer unprofessional for naming a LUT in the ways that we can agree they probably should or saying (I don’t think you meant it this way) that using them is unprofessional.

    3. I have to agree with Pat that what matters most to me is what ends up on screen – that’s what clients are paying for. That is of course not to discount a level of knowledge that should be required by a ‘colorist’ to be conversant in the LUTs or other parts of modern color grading.

    With that said,I know many very very successful colorists working on huge projects that make beautiful images that couldn’t tell you anything about the particulars of a LUT, a knob or slider in their grading tool other then they like what it does to the footage they’re working with.

    And while I 100% see the logic of understanding why a LUT wasn’t working in a particular situation and breaking down the math to figure out the ‘why’, I don’t think its the only thing that matters. Personally, I’ve never been a grade by numbers type guy – I’ve used creative LUTs over the years that SUCKED and did all sorts of horrible things to images on close inspection – noise, banding etc, but the I and most importantly my clients LOVED the way the looked. I don’t think that makes me less of a colorist, or my clients opinions any less valid. Yes the technical side is vitally important in our field but so is look and feel.

    4. I’m eager to go through your post/article on LUTs when I’ve had a bit of sleep – I’ve been in the air for 15 hours and I’m writing this at baggage claim waiting for my luggage!

  • Using a LUT or Color Management helps keep a level of consistency that I find difficult if not impossible when just twisting the knobs to go from LogC to Rec.709. Yes you can make a good looking image, but shot matching will likely be much more difficult. My 2cents.


  • pauljohndore
    Guest

    Anything I’ve posted in that thread is available for public consumption, so everyone is welcome to incorporate it into their own interpretations. Of course the civil thing would be to mention the source, but whether or not that occurs is of no great concern to me. I would, however, like there to be more of a conversation with regards to the subject matter so anything that might facilitate that would have my support, plus I am interested in what people think of it once they’ve had a chance to give it a read. Hopefully it didn’t prolong the effects of your jet-lag 🙂

  • Hi Robbie,

    100% agree with you. No matter what the numbers say, if if looks good it looks good and visa versa. The end goal is getting the image to look a certain way, not getting the math right. I found myself (as i love the technical aspect and use Nuke for example to create all kinds of technical transformation luts) way too much focused on the technicality, until i let go of that completely.
    The only thing you need to know is the pitfalls of a lut like you mentioned in this insight.
    The most important revelation for me some time ago was the destructive clipping compared to resolves non destructive clipping of blacks and whites.
    Similarly to , i think it was in a previous insight , to take care of your cache format setting, which if not high bit range , can cause similar hidden clipping. (not lut specific but same sort of data loss)
    Other then that its open season and I just use them creatively, with pre and post adjustments where needed. I think the only time i am still using technical luts is for xyz conversions etc.


  • pauljohndore
    Guest

    It should probably be reiterated that it is not simply a case of either/or, rather it should be the combination of both sets of skills. At the end of the day it is the final image that counts, absolutely, but in the long run it is surely better to have a healthy level of technical knowledge to go along with an artistic vision, if only for the reason that the ‘competition’ probably will and therefore have a likely advantage in securing work. I believe there is a considerable anxiety amongst many colourists at the prospect of learning something new and seemingly complicated, but this fear can be dispelled though education. It’s nowhere near as terrifying as some people fear, and should be viewed as a means of empowerment by those eager to advance their creative ability. These are just my opinions though, so each to their own.

    Having said all that, it is often those who have the least understanding of math and colour science that are the loudest in dismissing their importance to the colour grading process, and so I suggest caution from taking advice from those who are perhaps more interested in preserving their own sense of significance than progressing the community as a whole. As always, a balanced view should come from a near equal comprehension of both sides of the argument.

  • Will not go into the suggestive remarks (intended or by accident) towards people devoted to actualy sharing their knowledge on this site rather then (as often customary) hiding their tricks for their own convenience, but rather give my personal example of how ignoring one side can greatly benefit you sometimes.
    Myself i grew up as a scientist (aerospace engineer) and later focused heavily on computer science (where at that time there was more future for me) which in the end made my career and business. But have always been into some form of artistic endevor. Starting as an audio engineer in the start of electronic music era (in the pioneering time when working with modular synthesis) , and sound designer , later diving more into video and more recently into compositing and vfx, just out of pure interest and assisting others with their projects. Math always had a huge importance and i tried and still do, to understand them to the deepest part (specialy working with stuff like nuke and houdini are extremely demanding).
    My wife, a visual artist understands zero to nothing from all that science and we started working together where i took care of her technology (creating video installation , programmed / build her software tools , compositing and grading etc etc.
    In lots of our initial discussion on her projects , we started arguing , mainly me explaining her why her project would not work because the math/science was incorrect, the colors where wrong,etc etc.
    In the end she won the arguments (women always win arguments) and just ignored my science babble and did her thing and i just worked on her direction doing my tricks without having any faith in the end product. In all these cases she ended up winning awards, reaching huge audiences and laughing at me in my face.
    Over the years i started adopting more her view of the art and split the science of as follows.
    I use the science to create and understand tools . Then i switch off science and rationale and use the tools like a painter would who is not worried how his brusher where fabricated , if they are composed of exactly so many threads in the right angle if his canvas is exactly mathematicaly a correct rectangle bla bla bla.
    VFX artist work in a similar way ofter, where they get tools (for example a complete houdini digital asset rigged and ready to animate) from the “techies” and then they use their artistic feeling to create the magic.

    So you are right in saying that there is place for both science and pure artistic feeling, but very wrong in the statement that you need to be equally skilled in both to succeed.
    In fact your mathematical or scientific view more then often (as is no mystery) blocks your creativity which is not composed of logic and often counter intuitive. Ask mister Spock ……
    I dont think that any director would give a damn if you are a wizzard in your tools and can explain every mathematical translation that would result in the shift of mangenta visible and that you user a technicaly correct lut , if you can not deliver the artistic end result he/she is looking for, but would embrace you if the reverse is true.
    Tricks can be learned, any trick , any software anything given enough time. If people say that is not the case i will prove them wrong every time ( i learned fluent Portuguese in 6 weeks while failing for years at school to learn any language. Now i speak 6 languages)
    Artistic feelings can not. You have them or not (in varying degrees). Period.

    I love eat breath science in all my cells, but any day any time any second i would welcome advise from a true artist in the field that works by his guts and gladly ignore a science blabermouths advise on art. (including myself)

    The best tools for artists let you forget the underlying math, do not “force” you to learn it but enable you to create. I had that after struggling for years in dozens of linear track based sound/music recording/editing tools and did not understand why i would never finish tracks or always got stuck in the technical details of setting up connections etc. Thats because scientists build the tools and not artists. Until Ableton Live was released (build by an artist).
    Within one week i finished 10 tracks and the software became the de-facto standard for live sound/music creation due to its intuitive and creative nature.

    Resolve is well on its way (although definately has its challenges) being such a tool where (with a proper control surface, which in my case i just created myself) you forget about color science and just move knobs , wheels and balls to get the look you want. I point my wife to the knobs (she is also a profession photographer) and she now hates photoshop for obvious reasons. We actualy do some photo work in resolve now in 10% of the time.

    To end my blabering, Robby takes in this post the right approach in giving the artist enough info to not distract from the art , but not to get trapped by the science of using luts. There are enough posts (and linked by him) to dive deeper if one wants.
    Thats also what i loved from Patricks Flight School. Yes he talk some base techie stuff (basicaly what is a pencil and how best to use which pencil for what), but focus on the creative part , more on the why , when then the how (as here are always dozens of ways to achieve the same) , a welcome exception to all the dozens of other resolve courses on the market that just learn you how to use resolve.
    Thumbs up for this approach in a sea of technology focused resources. (unless you give me now the lut to do shotmatching, and aother one to create the perfect look on any footange then i give up)
